TECHNICAL DATA
FLS stator leakage sensor
Signal: 8 mA non-alarm current,
36 mA alarm current
Supply voltage: 12 VDC
Max. temperature: 90°C, 1h
Test temperature: 115°C, 1h
Max. duty temperature: 70°C
Material: Aluminium
Physical size, sensor
Length: 27 mm
Width: 16 mm
Height: 16 mm
Part Number 518 89 02
CLS water in oil sensor
Trip emulsion: 35% of water in oil
Signal: 5.5 mA non-alarm current,
29mA alarm current
(5 s delay of alarm)
Poles: 2 wires protected with a
diode (wrong polarity
connection = 0 mA)
Supply voltage: 12 VDC (± 10 %)
(brown = +. black = –)
Metal parts: Acid proof stainless steel
Sensor surface: Glass
Max. pressure: 10 MPa 1h
Test pressure: 40 MPa
Duty pressure: 2 MPa
Max. temperature: 90°C, 1h
Test temperature: 115°C, 1h
Max. duty temperature 70°C
Physical size, sensor
Length: 75 mm
Diameter: 12 mm
Thread: M16 × 1.5, length 15 mm
Part number: 505 12 00
Warning: Sensor body made of glass.
Handle with care.
FLS10 inspection chamber sensor
Signal: 10 mA non-alarm current,
28 mA alarm current
Supply voltage: 12VDC
Max. duty temperature: 90°C
Material: Stainless steel and
nitril rubber
Physical size, sensor
Length: 44 mm
Diameter: 22 mm
Thread: M12 × 1, length 9 mm
Part number 608 26 00
