Flymo H400 User Manual

Problem Possible Cause Remedy
Abnormal noises Screws / components loose. v Tighten screws.
Foreign bodies on the blade. v Remove foreign bodies.
Notch in the blade. v Remove notches with
grindstone.
Blades are striking each other
too hard.
v Adjust cutting mechanism.
Lawn is not cleanly cut Blade adjustment incorrect. v Adjust cutting mechanism.
Blade blunt or damaged. v Have the blade replaced by
FLYMO Service.
Grass too long (e. g. after
a relatively long absence).
v Cut lawn shorter with
a sickle.
Adjusting the cutting mechanism:
The cutting gear of your cylinder mower was optimally adjusted before
leaving our company. If, after longer use, a clean cut of the grass is no
longer possible or the blade roller contacts the lower blade, then the
lower blade should be adjusted as follows:
1. Clean the cylinder mower.
2. Lay the mower onto the ground, so that it cannot fall over when
adjusting the cutting mechanism.
3. Check cylinder and lower blade for notches and remove these with
agrindstone if necessary.
4. Unscrew the left and right hexagon screws using a hexagon wrench
(10 mm) anticlockwise until the blade cylinder can only just turn freely.
5. Carefully tighten the left hexagon screw using a hexagon wrench
(10 mm) whilst the blade cylinder rotates, until it lightly contacts the
lower blade.
6. Then unscrew the left hexagon screw again until the blade cylinder
just stops contacting the lower blade (rotates soundlessly).
7. Repeat the process on the right-hand side.
8. Cutting test:
Place a strip of paper in such a way on the lower blade that it points
towards the spindle of the cylinder.
9. Turn cylinder carefully.
If the lower blade is set correctly the paper will be cut off as if with
scissors.
10. Repeat the cutting test at different positions and on all blades on the
blade cylinder.
Regrinding / Repairs:
On safety grounds, only original FLYMO spares may be
used.
Please contact FLYMO Service if it is necessary to replace the cutting
tool, which will only become blunt after several years use if well-main-
tained. Repairs to the cylinder mower and the installation of the blades
can be undertaken by suitable specialist workshops.
Have the cylinder mower checked over in the autumn if possible so
that it is ready for use immediately when the next lawn-mowing season
starts.
For any other malfunctions please contact the FLYMO service depart-
ment.
Let the blade replace by the FLYMO service or a specialist dealer author-
ised by FLYMO.
6. TECHNICAL DATA
Unit Value FLYMO H400
Cutting width cm 40
Cutting height mm 12 – 38
Cutting height adjustment
(4-stages)
mm 12, 20, 28, 38
Weight kg 8.3
7. SERVICE / WARRANTY
Service:
Please contact the address on the back page.
Warranty statement:
In the event of a warranty claim, no charge is levied to you for the services
provided.
Husqvarna UK Ltd. grants a warranty for all original FLYMO new products
for two years from the date of original purchase from the retailer, provided
that the devices have been for private use only. This manufacturer’s war-
ranty does not apply to products acquired second hand. This warranty
includes all significant defects of the product that can be proved to be
material or manufacturing faults. This war ranty is fulfilled by supplying
afully functional replacement product or by repairing the faulty product
sent to us free of charge; we reserve the right to choose between these
options. This service is subject to the following provisions:
• The product has been used for its intended purpose as per the recom-
mendations in the operating instructions.
• Neither the purchaser nor a third party has attempted to open or repair
the product.
• Only Original FLYMO replacement parts and wear parts have been used
for operation.
• Presentation of the receipt.
Normal wear and tear of parts and components (such as blades, blade fix-
ing parts, turbines, light bulbs, V-belts / toothed belts, impellers, air filters,
spark plugs), visual changes, wear parts and consumables are excluded
from the warranty.
This manufacturer’s warranty is limited to replacement and repair of prod-
ucts in accordance with the abovementioned conditions. The manufactur-
er’s warranty does not constitute an entitlement to lodge other claims
against us as a manufacturer, such as for damages. This manufacturer’s
warranty does not, of course, affect statutory and contractual warranty
claims against the dealer / retailer.
The manufacturer’s warranty is governed by the law of the Federal
Republic of Germany.
In case of a warranty claim, please return the faulty product, together with
a copy of the receipt and a description of the fault, with postage paid to
the service address.
Consumables:
The blade is a consumable and is not included in the warranty.
PRODUCT LIABILITY
In accordance with the German Product Liability Act, we hereby expressly
declare that we accept no liability for damage incurred from our prod-
uctswhere said products have not been properly repaired by a FLYMO-
approved service partner or where original FLYMO parts or parts author-
ised by FLYMO were not used.
SERVICE ADDRESS AND IMPORTER TO
Great Britain
Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
Phone:+44 (0) 344 8444558
customer.services@husqvarna.co.uk
Our policy of continuous improvement means that the specification of products may be altered from
time to time without prior notice.
Copyright © 2022 Flymo S.A. All rights reserved.
Flymo
®
and other product and feature names are registered or unregistered trademarks of Flymo S.A.
20400-85.960.01/0322
Husqvarna AB
Drottninggatan 2
SE-561 82 Huskvarna
Sweden
2
20400-85.960.01.indd 220400-85.960.01.indd 2 02.03.22 10:4202.03.22 10:42
