FNM® Series HPE – Installation Manual – 33
Table of
contents
Name
Description
1
Three-position key
lock
It allows to start and stop the
engine.
2
Rpm counter
(Master Tool)
It measures the engine crankshaft
speed rotation in RPM
(revolutions per minute).
3
CANBUS universal
instrument
It allows to display all the engine
operating parameters and alarms.
4
MODE button
To change the operating mode of
the CANBUS Universal Instrument.
5
Direction buttons
They allow you to scroll through
the CANBUS Universal Tool menu
6
Glows plugs pilot
lamp
It lights on during the glow plugs
preheating phase, with the key
lock in position I and engine off.
7
Transmission oil
anomaly pilot
lamp
It lights up in case of problems
with the transmission lubrication.
It requires the sensor connection.
8
Other pilot lamps
Optional
Size and dimensions of the panels are shown in the following
table:
Panel
Fastening
Fastening
Holes
Position
[mm]
Panel Overall
Dimensions
[mm]
Perforation
template
Assembled
4 M4
screws
200 x 150
219 x 169
Attached to
the manual
Separate
4 M4
screws
80 x 70
160 x 99
Attached to
the manual
The CANBUS Universal Tool allows to display all the engine
operating parameters.
- Volts: is the operating voltage of the battery in volts.
- Trim: is the position proportional to the trim inclination
angle.
The Trim location information is only available in
applications that require the adjustment of the trim,
such as the stern drive.
- Oil Press: is the engine oil pressure in bar or PSI.
- Engine Hour: is the total number of running hours of your
marine engine.
- Fuel Level e Fuel Left: is the indication of the fuel level in
the tank (it requires an additional sensor).
- Water Press: is the engine coolant pressure.
- Fuel Used: is the amount of fuel used since last reset of
the instrument (it requires an additional sensor).
- Trans Gear: shows the current gear engaged in the
transmission (it requires an additional sensor).
- Trans Temp: indicates the current oil temperature in the
transmission (it requires an additional sensor).
- Trans Press: indicates the current oil pressure in the
transmission (it requires an additional sensor).
- Boost Press: shows the current engine boost pressure
(turbocharger boost pressure).
- Throttle o Engine Load: show the percentage relative to
the position of the throttle.
- Coolant Tmp: shows the engine coolant temperature.
- Water Level/Temp: shows the level or the temperature of
water in the optional tank (e.g.. household users, requires
an additional sensor, and the speedometer tool).
- Rudder Angle: shows the rudder angle (it requires an
additional sensor).
- Speed: shows the boat speed in knots or km/h (it requires
an additional sensor, and the speedometer tool). Not
compatible with the Air Temp measurement).
- Air temp: shows the air external temperature (it requires
an additional sensor, and the speedometer tool). Not
compatible with the speed measurement).
It is possible to add to the standard supply also one or more
additional tools that allow you to view the following information
with a needle:
Tool
Connection
Dimensions (in)
Hole diameter [mm]
Function shown
Order code
Master
Speedometer
Master
5”
111.3
(4 3/8 in)
Engine revs
(rpm)
4.049.086.1
4”
85
(2 3/8 in)
4.049.082.1
Master
Speedometer
-
4”
85
(2 3/8 in)
Speed
(knots)
4.049.084.1
Trim
Slave
2”
52.4
(2 1/16 in)
angle
4.049.079.1
Battery
Slave
2”
52.4
(2 1/16 in)
voltage
(volts)
4.049.078.1
Fuel level
Slave
2”
52.4
(2 1/16 in)
volume
(litres)
4.049.076.1
Engine
temperature
Slave
2”
52.4
(2 1/16 in)
temperature
(°C)
4.049.075.1
Oil pressure
Slave
2”
52.4
(2 1/16 in)
pressure
(bar)
4.049.077.1
Water level
Slave
2”
52.4
(2 1/16 in)
volume
(litres)
4.049.080.1
Rudder angle
Slave
2”
52.4
(2 1/16 in)
angle
4.049.081.1
For each instrument with slave connection in
addition to the first, a Master-Slave connection cable
code 1.010.117.1 (l = 30cm/12in) or code
1.010.119.1 (l = 100cm/39in) is required.
