FNM HPE Series Installation Manual

FNM® Series HPE – Installation Manual – 3
2 Engine technical data
2.1 Product identification
HPE series marine engines are divided into classes depending
on the family and application to which they are intended:
Model (or Engine Type)
Family
Application
HPE 40S/80/80SD/110
HPE 110JD/135JD
1.3HPE
Yachting
HPE/P 40/150/170/190/205
HPE 150JD/170JD/190JD/205JD
1.9HPE
Yachting
HPE/P 100/225/250/250H
HPE 225JD/250JD
2.4HPE
Yachting
HPE/P 300
HPE 300JD
3.0HPE
Yachting
HPEL 45/80
1.3HPE
Work
HPEL 65/90
1.9HPE
Work
2.1.1 ID label
The ID label is applied on the engine and on the control unit
(or ECU Box), in the position indicated in the table below (see
also paragraph 3.3 - Engine elements on page 8):
Engine
Label position on the engine
1.3HPE
1.9HPE
On the engine crankcase.
2.4HPE
On top of the engine, attached to the intercooler housing.
3.0HPE
On the cooled exhaust manifold on the right side of the
engine.
The data that are found on the identification label are given
below as an example:
- Engine Type
- Engine Family according to RCD (CE).
- Engine Serial No.
- Year of manufacture
- Test speed (Rpm)
- Power in kW (kW)
- Horsepower (HP)
2.1.2 Engine serial No.
The engine serial number is also printed on the engine block.
The location is shown in the table below (see also paragraph
1.6 - Main components of the engine FNM HPE Series ® - on
page 16):
Engine
Engine serial number position
1.3HPE
1.9HPE
2.4HPE
On the right side of the crankcase, bell housing connection,
or on the front side of the crankcase, above the bell
housing.
3.0HPE
On the crankcase, front side, above the bell housing.
The serial number of the engine is constituted as follows:
Position
1
2
3
4
5
6
7
Serial
number
4
7
1
1
0
X
X
Positions 1-2:
Identification code of the model.
Positions 3-4:
Last two figures of the engine year of
production
Positions 5-7:
Progressive
Besides the engine also the transmission, transom and stern
drive have their own serial number, indicated on each of them
by the respective manufacturers.
Communicate to CMD the serial number of each element of
the propulsion system whenever you require any maintenance.
2.1.3 EPA/IMO Label
The engine can be provided with a label which indicates the
presence of EPA certification and/or IMO MARPOL Annex IV
pre-certification.
The label is usually affixed near the identification label and
reports the EPA/IMO family number. If the engine is equipped
with IMO MARPOL Annex IV (NOx), pre-certification, the
information regarding the pre-certification is contained in the
certificate attached to the engine.
2.2 Documentation attached
The HPE marine diesel engines are accompanied by the
following documentation:
- Use and Maintenance manual
- Installation Manual (this document)
- Installation Form
Costruzioni Motori Diesel SpA
Z.I. Valle di Vitalba
85020 Atella (PZ) Italy
Engine Type: HPE110
Engine Family: 13T4L550
Serial No.: 47110XX Year: 2011
Rpm: 4400 kW: 80.88 HP:110
