4 – FNM® Series HPE – Installation Manual
- Transmission manual (if any)
- Quick Reference Guide for the CANBUS instrument use
2.3 Leisure engine technical data
1.3HPE
1.9HPE
2.4HPE
3.0HPE
Cylinders
4
4
5
4
Displacement
[cm
3
]
1248
1910
2387
2988
Bore [mm]
69.6
82.0
82.0
95.8
Stroke[mm]
82.0
90.4
90.4
104.0
Engine type
Four stroke diesel engine -
Compression
ratio
17,6:1
18:1
Injection Type
Direct Common Rail Injection
Boosting
Turbine with variable
geometry
Turbine
with cooled
turbocarter
Turbine with
cooled body
Timing system
16-Valve DOHC
20-Valve
DOHC
16-Valve
DOHC
Firing order
1-3-4-2
1-2-4-5-3
1-3-4-2
Alternator
75A 12V
105A 12V
140A 12V
110A 12V
Engine oil
capacity (without
filter) [l]
3.2
4.0
4.5
7.5
Thermostatic
valve
65°C ± 1.5°C
(88°C for 1.3HPE MK3)
65°C±1,5°C
80°C
±1,5°C
Cooling capacity
[l]
7.5
7.5
8.5
14.0
Sea water pump
flow [l/min]
90 (24,0
gal/min)
100 (26,6 gal/min)
Engine starter
1.3 kW
12V
1.8 kW 12V
2.6 kW 12V
Wet weight
(excluding
transmission)
[kg]
188
240
295
335
Direction of
rotation of the
flywheel
Counterclockwise (bell housing side)
For all rating data (torque and power), refer to the table in
paragraph 2.5 on page 4.
2.4 Work engines technical data:
HPEL 45
HPEL 80
HPEL 65/90
Cylinders
4
4
Displacement [cm
3
]
1248
1910
Bore [mm]
69.6
82.0
Stroke[mm]
82.0
90.4
Engine type
Four stroke diesel engine -
Compression ratio
17,6:1
18:1
Injection Type
Direct Common Rail Injection
Boosting
aspirated
Turbine with variable geometry
Timing system
16-Valve DOHC
Firing order
1-3-4-2
Alternator
75A 12V
105A 12V
Engine oil capacity
(without filter) [l]
3.2
4.0
Thermostatic valve
65°C ± 1.5°C
Cooling capacity [l]
7.5
7.5
Sea water pump flow
[l/min]
90 (24,0 gal/min)
100 (26,6
gal/min)
Engine starter
1.3 kW 12V
1.8 kW 12V
Wet weight (excluding
transmission) [kg]
158
188
240
Direction of rotation of
the flywheel
Counterclockwise (bell housing side)
For all rating data (torque and power), refer to the table in
paragraph 2.5 on page 4.
2.5 Power, Torque and Operating cycles of
Diesel Marine Engines FNM® series HPE
FNM® diesel marine engines are designed to operate within
the range of minimum and maximum speeds shown in the
table.
Power and maximum torque are achieved at the speeds
indicated:
