HPE Series 29
Figure 8- Complete digital instrument panel
Figure 9 - Analog instrument panel in
separate configuration
2.2.1 The universal CANBUS instrument
The digital instrument panel features a LCD display and some buttons that make up the CANBUS
universal instrument. The instrument is capable of displaying various information of the engine.
1
6
7
8
3
2
1
4
5
6
8
7
