Fitting the crossover
Locate the crossovers in a dry, preferably
ventilated area, using either the screws
supplied or double-sided tape.
To open the box, squeeze the middle on the
side, and remove the cover.
In some cases, depending on your installation
and the space available, it maybe easier to
route the cables and connect to the crossover,
before securing the crossover to the vehicle.
Please check before.
Level adjustment of tweeter and midrange
The toggle switch found inside the crossover, allows the user to adjust the tweeter level (and
mid-range level for 130V2 and 165V2). This user-friendly option allows effective adjustments
to be made, to your own personal listening pleasure, plus optimising the infinite amount of
speaker installation locations available.
This allows the system to be “tailor made” to your vehicle, effectively ensuring the best
acoustics are possible. Remember too much treble and your system may sound aggressive,
thus suffer a lose of dynamics, resulting in poor definition.
“FULL” position for adjustment of the midrange (130V2 and 165V2), if the speakers are
positioned low in the vehicle (low in door or kick-panels).
Level of “FULL” position 0 or -3dB, if the tweeter is located very close to woofer-midrange.
Level of “FULL” position -3dB or -6dB, if the tweeter is located high in the vehicle (in the dash
or high in the doors) with the woofer positioned comparatively low.
Mid-range level adjustment
“FULL” and “FILTER”
(for 130V2 and 165V2)
Tweeter level adjustment
0, –3dB and -6dB
4
Polyglass Multi Speaker Manual
