CMS SUB
User Manual
19
System CMS SUB
• Frequency response (+/- 3dB)
30Hz - 250Hz
• Maximum SPL
113dB SPL (peak @ 1 m)
Electronic section
• Input - Type/Impedance
- Connector
- Sensitivity
Left, Right, LFE
Electronically balanced / 10kOhms
Female 3 pins XLR
Variable
• Output (to satellites) - Connector
Left, Right
Male 3 pins XLR in parallel on inputs
• Amplifier - 300 W rms, BASHtechnology
• Internal processing and functions - Subwoofer section
Left + Right mono summation
LFE + lo-passed mono sum
24dB/octave variable lo-pass filter
Phase adjustment
Polarity
• User controls
Sub level (sensitivity) adjustment
Lo-pass frequency adjustment
Phase adjustment
Polarity switch
Mute
External Mute (controlled by external footswitch)
• Indicators (LED’s)
Power on
Mute
External Mute
• Power supply - Mains voltage
- Connection
230V (T1.6AL fuse rating) or 115V (T3.15AL fuse rating)
IEC inlet and detachable power cord
Transducers
• Subwoofer
Polyglass, high excursion Focal, 270mm (11”) drive unit
Cabinet
• Construction
22mm MDF panels with internal braces
• Finish
Dark grey vinyl
• Dimensions (HxWxD)
435,5mm x 366mm x 440mm (17.1” x 14.4”x 17.3”)
•Weight
23kg (50.7lb)
