CMS SUB
User Manual
System CMS SUB
• Frequency response (+/- 3dB)
30Hz - 250Hz
• Maximum SPL
113dB SPL (peak @ 1 m)
Electronic section
• Input - Type/Impedance
- Connector
- Sensitivity
Left, Right, LFE
Electronically balanced / 10kOhms
Female 3 pins XLR
Variable
• Output (to satellites) - Connector
Left, Right
Male 3 pins XLR in parallel on inputs
• Amplifier - 300 W rms, BASHtechnology
• Internal processing and functions - Subwoofer section
Left + Right mono summation
LFE + lo-passed mono sum
24dB/octave variable lo-pass filter
Phase adjustment
Polarity
• User controls
Sub level (sensitivity) adjustment
Lo-pass frequency adjustment
Phase adjustment
Polarity switch
Mute
External Mute (controlled by external footswitch)
• Indicators (LED’s)
Power on
Mute
External Mute
• Power supply - Mains voltage
- Connection
230V (T1.6AL fuse rating) or 115V (T3.15AL fuse rating)
IEC inlet and detachable power cord
Tr a n sd u c e r s
• Subwoofer
Polyglass, high excursion Focal, 270mm (11”) drive unit
Cabinet
• Construction
22mm MDF panels with internal braces
• Finish
Dark grey vinyl
• Dimensions (HxWxD)
435,5mm x 366mm x 440mm (17.1” x 14.4”x 17.3”)
•Weight
23kg (50.7lb)
Due to constant technological advances, Focal reserves its right to modify specifications without notice. Images may not conform exactly to specific product.
Your Focal-JMlab product was developed and manufactured with high-quality materials and components which can be
recycled and/or re-used. This symbol indicates that electrical and electronic equipment must be disposed of separately
from normal garbage at the end of its operational lifetime.Please dispose of this product by bringing it to your local
collection point or recycling centre for such equipment. This will help to protect the environment in which we all live.
