15
ELITE K2 POWER
User manual
Installation of the tweeter (Kits ES165KX2 and 165KX3)
There are two mounting options:
1 - Mounting on the inclined pod: choose the desired tilt according to the selected place. (Fig M1)
Mount the stand using the screws provided, thread the wires and then mount the tweeter in its housing (adjusted
mounting). Reinstall the grille.
2 - Flush mounting: cut out a 51 mm in diameter hole: “Tight” adjustment. (Fig M2)
The serrated steel washer (provided) maintains the pressure of the tweeter after it has been mounted in its housing.
Coaxial kit EC165 K (Fig S)
This coaxial kit is equipped with an integrated tweeter crossover (6 db/oct); please observe the general
recommendations for installation.
Warning: The tweeter post is not adjustable or rotative: it has been designed to be as compact as possible and
thus compatible with as many spaces as possible.
