ELITE  UTOPIA BE ULTIMA
User manual
Fs 62Hz
Vas 13.5 liters
Qts 0.71
Qes 0.76
Qms 9.8
Re 3.9Ω
Sd 120cm
2
Cas 7.22E-08m
5
/N
Mas 82.28kg/m
4
Ras 3376Ω.ac
Cms 515µm/N
Mms 12.7g
Rms 0.49kg/s
Ces 481.7mF
Les 12.3mH
Res 50.6Ω
BI 5N/A
SPL 88.1dB/W/m
Nominal power 120W
Maximum power 240W
Sensitivity (2,83V/1m) 90.5dB
Cone W
Surround Butyl
Nom. impedance 4Ω
DC resistance 3Ω
VC diameter 40mm 1
9/16
"
VC height 17mm 0
2/3
"
Former Kapton
Layers 2
Wire Alu
Inductance -
Xmax ± 5.5mm (0
3/16
")
Magnet d x h 122mm x 32mm 4
13/16
" x 1
1/4
"
Magnet weight 1.56kg 3.44lbs
Flux density -
Gap height 6mm 0
1/4
"
Net weight 2.05g 4.52lbs
Woofers
