60/30/15 W
all RAL colours
weatherproof
EASE
8. Specifications
This equipment conforms to standards EN 61000-6-1, EN 61000-6-3 and EN 60065
We reserve the right to alter the specifications without notice.
Linea LX-11 / LX-100 / LX-150
Type Linea LX-100
electro-acoustical features
acoustic design line source speaker system,
2-way
components [*] 8x 4“ impreg. speaker membranes and
1x 1“ on Waveguide
power rating (nominal) [1] 400 W
power rating (program) [2] 800 W
power rating (peak) [3] 1600 W
sensitivity [4] 94 dB
maximum SPL [3] 126 dB
frequency range [5] 65 Hz - 20 kHz
nominal dispersion (h x v) [6] 140° x 25°
nominal impedance 8 ohms
features
enclosure Aluminium design
protection grille metal, powder coating
suspension points 8x M6 thread
connectors 2x Neutrik NL4 Speakon and
8-pin Phoenix terminal
standard colours black or white powder coating
front design metal grille in enclosure colour
dimensions (W x H x D) 130 x 990 x 120 mm
weight [7] 7 kg
optional features
integrated 100 V-transformer 60/30/15 W
optional colours all RAL colours
weather resistance weatherproof
CAAD simulation data EASE
-10 dB under anechoic halfspace-conditions
horizontal x vertical at -6 dB
net weight without optional equipment
Intelligent Protection Circuit. Voltage-controlled semiconductor circuit
protecting the HF-driver against overload highly effective and with very
short attack time
[5]
[6]
[7]
[*]
according to IEC-60268-5 long term
according to IEC-60268-5 short term
Peak, 20 ms with band-filtered pink noise signal according to
IEC 60268-2 at one octave above the lower limit of the frequency range
2,83 V at 8 ohms (2 V at 4 ohms, 4 V at 16 ohms) at a distance of 1
meter under anechoic fullspace conditions
[1]
[2]
[3]
[4]
42 | Fohhn
