EXPLODED DIAGRAMS
F-G15
57
129
128
134
128
15
14
7
7
132
37
36
37
131
6
6
130
130
133
15
14
7
M10x25 1
Hexagon Bolt
ɸ10 3
Spring Washer
ɸ10 3
Washer
130 8
Pulley Bracket
37
131
36
ɸ92 1
Pulley
ɸ60 2 Pulley
M10x45
2
Hexagon Bolt
6 M10 2
Lock Nut
No.
Note QTTY
Description
134
128
129
1
Tube Handle Right
50-60 2
Plug
M20x1.5-ɸ10 1
Pin
132
ɸ19.8x49.5 1
Internal Thread Shaft
133
ɸ33xɸ29xɸ20x18 2
Powder Metallurgy Sleeve
Sliding Frame Right
1 pcs/set
