Assembly step 10
25
No.
Descripon
Note
Qty.
74
shield
1
75
barbell plate holder
6
76
hexagon bolt
M8x20
16
77
washer
Φ8
20
78
lock nut
M8
4
76
74
77
75
78
77
75
76
77
