Force USA F100 - Page 19

Assembly steps
Step
NO
Item NO Name Qty Item NO Name Qty
11
NO 56 cable 2 NO 43 Rubber cover 2
NO 40 Safety hook 2 NO 44
Small
aluminum
cap
2
NO 41 Low pull bar 2
NO 42 Card slot set 2
Tools No.4 ,6hexagon socket screw driver,wrench
Note that the two ends of the wire rope are divided into large and small ends, pay attention to the direction
of the joint, and remove the two pulleys at the bottom of the base when threading.
19
