Assembly steps
Step
NO
Item NO Name Qty Item NO Name Qty
17
NO 32 Right lower cover 2 F Locknut M10 18
NO 33 Left lower cover 2
A
Hexagon flat head screw
M10*100
18
G Flat washer Ø10 18
Tools
Pay attention to distinguish the left and right guard plates, as shown in the picture, the large hole guard
plate is on the outside.
