15. Install fuel charging wiring (9D930) to fuel injectors and inboard rocker arm cover studs. Connect fuel
charging wiring to engine control sensor wiring (12A581) and secure with retaining features.
16. Install throttle body and new intake manifold gasket (9439) as outlined. Refer to Section 03-04B .
17. If left cylinder head was removed, perform the following:
a. Install three bolts securing power steering pump support bracket to front of left cylinder head,
finger tight only.
b. Install stud bolt at left side of power steering pump support bracket. Tighten all five bolts
securing power steering pump support bracket to engine block and cylinder head to 40-62 Nm
file://C:\TSO\tsocache\VDTOM_5368\SVK~us~en~file=SVK31B18.HTM~gen~ref.HTM
