Ford 2000 Ranger Workshop Manual

 Is any voltage indicated?
Yes
REPAIR circuit 275 (Y). CLEAR the DTCs. TEST the system for normal operation.
No
REPLACE the GEM; REFER to Section 419-10. CLEAR the DTCs. TEST the system for normal operation.
A21 CHECK THE ELECTRIC SHIFT RELAY COIL CIRCUIT — MONITOR THE GEM PID 4WDELCL
Trigger the GEM active command SHIFT CLUTCH to OFF.
Monitor the GEM PID 4WDELCL.
 Does the GEM PID 4WDELCL display OFF--?
Yes
GO to A36.
No
If the PID displays OFFO-G, GO to A22 .
A22 CHECK THE BATTERY SAVER RELAY
Check the battery saver relay; refer to Component Test.
 Is the battery saver relay OK?
Yes
GO to A23.
No
REPLACE the battery saver relay. CLEAR the DTCs. TEST the system for normal operation.
A23 CHECK THE BATTERY SAVER RELAY COIL CIRCUIT — MONITOR THE GEM PID BATT_SAVE
Battery Saver Relay
Trigger the GEM active command BATT_SAVR to ON.
Monitor the GEM PID BATT_SAVR.
 Does the GEM PID BATT_SAVR display ON---?
Yes
GO to A25.
No
If the GEM PID BATT_SAVR displays ON-B-, GO to A24 .
A24 CHECK CIRCUIT 1005 (P/O) FOR SHORT TO POWER
Battery Saver Relay
GEMC
Page
14
of
62
2000 Ranger Workshop Manual
