GEM/CTM Active Command Index
GEM/CTM Active Command Index
GEM/CTM Wiggle Test Diagnostic Trouble Code (DTC) Index
GEM/CTM Wiggle Test Diagnostic Trouble Code (DTC) Index
NTRL_SW Neutral Safety Switch Input NTRL, not NTRL
MTR_CCW Transmission Transfer CCW Motor Output (GEM Only) ON---, OFF---, OFFO-G, ON-B-
MTR_CW CW Shift Relay Coil Status (GEM Only) OFF---, ON---, OFFO-G, ON-B-
4WDCLCH 4WD Electronic Clutch Output Status (GEM Only) ON---, OFF---, OFFO-G, ON-B-
4WDLOW 4WD Low Indicator Status (GEM Only) ON---, OFF---, ON-B-, OFFO-G
4WDHIGH 4WD High Indicator Status (GEM Only) ON---, OFF---, ON-B-, OFFO-G
4WD_SW 4WD Switch Status (GEM Only) 2WD, 4WD HIGH, 4WD LOW
PLATE_A Transfer Case Contact Plate Switch A (GEM Only) OPEN, CLOSED
PLATE_B Transfer Case Contact Plate Switch B (GEM Only) OPEN, CLOSED
PLATE_C Transfer Case Contact Plate Switch C (GEM Only) OPEN, CLOSED
PLATE_D Transfer Case Contact Plate Switch D (GEM Only) OPEN, CLOSED
BOO_GEM Brake Pedal Position (BPP) Switch Input ON, OFF
PLATEPW Contact Plate Ground Output (GEM Only) ON---, OFF---
D_SBELT Driver Seat Belt Status OUT, IN
IPCHIME External Chime Request ON, OFF
SBLTMP Seat Belt Indicator Status OFF, ON, OFFO-G, ON-B-
DRAJR_L Door Ajar Warning Lamp Circuit OFF, ON
D_PWRLY One Touch Down Relay Coil Circuit Status (GEM Only) ON---, OFF---, ON-B-, OFFO-G
D_
PWAMP
Driver Power Window Regulator Electric Drive Current (GEM Only) 0.25 amp increments
D_PWPK Driver Power Window Regulator Electric Drive Peak Current (GEM Only) 0.25 amp increments
ACCDLY Accessory Delay Relay Coil Circuit (GEM Only) ON---, OFF---, ON-B -, OFFO-G
WPPK_PK Wiper Park-to-Park Time 0 - 6.5 Seconds
WPMODE Wiper Control Mode Status WASH, OPEN, INVLD, OFF, INTVL 1-7, LOW, HIGH
WPPRKSW Wiper Motor Status PARKED, notPRK
WPRUN Wiper Mode Run Relay ON---, OFF---, ON-B-, OFFO-G
WPHISP Wiper HI/LO Relay Status ON---, OFF---, ON-B-, OFFO-G
WASH_SW Washer Pump Relay Switch Status ON, OFF, ON-B-, OFFO-G
Active Command Display Action
PID LATCH PID LATCH ON, OFF
FRONT WIPER WIPER RLY ON, OFF
FRONT WIPER SPEED RLY ON, OFF
FRONT WIPER WASH RLY ON, OFF
WARNING LAMPS AND CHIME SBLT LAMP ON, OFF
WARNING LAMPS AND CHIME CHIME ON, OFF
WARNING LAMPS AND CHIME AJAR LAMP ON, OFF
BATTERY SAVER BATT SAVR ON, OFF
INTERIOR COURTESY LAMPS INT LAMPS ON, OFF
ONE TOUCH DOWN AND ACCY DELAY (GEM only) ACCY RLY ON, OFF
ONE TOUCH DOWN AND ACCY DELAY (GEM only) ONE TOUCH ON, OFF
4-WHEEL ELECTRONIC SHIFT (GEM only) CW/CCW ON, OFF
4-WHEEL ELECTRONIC SHIFT (GEM only) HIGH LAMP On, OFF
4-WHEEL ELECTRONIC SHIFT (GEM only) LOW LAMP ON, OFF
4-WHEEL ELECTRONIC SHIFT (GEM only) PLATE PWR ON, OFF
4-WHEEL ELECTRONIC SHIFT (GEM only) SHFT CLCH ON, OFF
SHIFT CLUTCH CONTROL CLUTCH SOL ANALOG %
DOOR LOCK CONTROL DD UNLOCK ON, OFF
DTC Description DTC Caused By
B1317 Battery Voltage HIGH GEM/CTM
B1318 Battery Voltage Low GEM/CTM
B1322 Driver Door Ajar Circuit Short to Ground GEM/CTM
B1330 Passenger Door Ajar Short to Ground GEM/CTM
B1352 Ignition Key-In Circuit Failure GEM/CTM
B1410 Driver Power Window Motor Circuit Failure GEM
B1438 Wiper Mode Select Switch Circuit Failure GEM/CTM
B1441 Wiper Mode Select Switch Short to Ground GEM/CTM
B1446 Wiper Park Sense Circuit Failure GEM/CTM
2000 Ranger Workshop Manual
