To remove the tonneau cover:
The tonneau cover needs to be
supported during removal. This is a
two person operation.
• Remove the cargo divider, refer
to To remove the cargo divider
in this procedure.
• Open and support the front
panel.
• Release two cylinder clips and
disconnect the hydraulic cylinders
from the pickup box and secure
them in the clips on the front
panel. Close the front panel.
• Stow the rear panel on top of the
front panel, refer to To stow the
rear panel in this procedure.
• Pull two release levers on the
underside of the tonneau cover
from the pickup box and remove the tonneau cover.
For installation of the tonneau cover, reverse the removal procedure.
Driver Controls
104
