Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
19 25A Powertrain Control Module (PCM)
power diode, Ignition, PATS
20 7.5A GEM, Radio
21 15A Hazard flasher
22 20A Auxiliary power socket
23 — Not used
24 7.5A Clutch Pedal Position (CPP)
switch, Starter interrupt relay
25 — Not used
26 10A Battery saver relay, Auxiliary relay
box, Restraint Central Module
(RCM), Generic Electronic
Module (GEM), Instrument
cluster
27 — Not used
28 7.5A GEM, Radio
29 20A Radio
30 — Not used
31 — Not used
32 — Not used
33 15A Headlamps, DRL module,
Instrument cluster
34 — Not used
35 15A or Not Used 15A: Horn relay (if not equipped
with a truck CSM)
36 — Not used
Roadside Emergencies
200
