4.6 Instrument Cluster
WARNING: Do not tamper with, cut
into or connect to any of the
CAN-Bus interface wiring or
connectors.
The Transit has a Hybrid electronic Cluster (HEC).
Most of the functions are managed over the
CAN-Bus interface (pins 3-8)
