Speedometer: Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section, the
engine is overheating; refer to
Engine coolant in the
Maintenance and Specifications chapter. Stop the vehicle as soon as
safely possible, switch off the engine and let the engine cool.
WARNING: Never remove the coolant reservoir cap while the
engine is running or hot.
Odometer: Registers the total miles (kilometers) of the vehicle.
• Standard instrument cluster
• Optional instrument cluster
Refer to Message center in the
Driver Controls chapter on how to
switch the display from English to
Metric.
2009 Explorer (exp)
Owners Guide, 1st Printing
USA (fus)
Instrument Cluster
19
