Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
36 10A** Back up lamps
37 10A** PCM run/start
38 5A** Illumination delayed accessory
39 Diode Fuel diode
40 Diode OTIS diode
41 G8VA relay A/C clutch
42 G8VA relay Fuel pump
43 G8VA relay Backup
44 G8VA relay Refrigerator
45 — Not used
46 15A** VPWR2, VPWR3
47 15A** PCM VPWR1
48 15A** PCM VPWR4
49 10A** Heated mirrors
50 Full ISO relay PCM relay
51 Full ISO relay Blower motor relay
52 Full ISO relay Starter relay
53 Full ISO relay Rear defrost relay
54 Full ISO relay Auxiliary blower motor relay
55 Full ISO relay Front wiper relay
56 — Not used
57 Full ISO relay Rear wiper relay
58 High current Battery charge relay (trailer tow)
* Cartridge Fuses ** Mini Fuses
2009 Flex (471)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
293
