Ford 2011 Escape - IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT

3.0L V6 engine
1. Engine coolant reservoir
2. Air filter assembly
3. Brake fluid reservoir
4. Automatic transmission fluid dipstick
5. Power distribution box
6. Battery
7. Coolant bleed valve
8. Engine oil dipstick
9. Engine oil filler cap
10. Windshield washer fluid reservoir
1
10
8
6
2
4
3
5
9
7
