2.0L EcoBoost engine (if equipped with drivebelt routing 1)
2.0L EcoBoost engine (if equipped with drivebelt routing 2)
A. Long drivebelt on the first pulley groove closer to the engine
B. Short drivebelt on the second pulley groove farther from the engine
A
B
386 Capacities and Specifications
2014 Explorer (exp)
Owners Guide gf, 1st Printing, April 2013
USA (fus)
