Ford 2015 Figo - Bulb Specification Chart

License Plate Lamp
3
2
1
E72789
1. Carefully release the spring clip.
2. Remove the lamp.
3. Remove the bulb.
Interior Lamp
E99452
2
3
1
1. Carefully remove the lamp.
2. Turn the bulb holder counterclockwise
and remove it.
3. Remove the bulb.
Luggage Compartment Lamp,
Footwell Lamp and Liftgate Lamp
E72784
1. Carefully pry out the lamp.
2. Remove the bulb.
BULB SPECIFICATION CHART
Power (watt)SpecificationLamp
21PY21WFront direction indicator
55/60H4Headlamp high beam / Low Beam
5W5WFront position lamp
55H11Front fog lamp
21/4P21/4WRear fog / position lamp
139
Figo (CDU) , E4B5 19A321 ZCA enIND, Edition date: 06/2015, Second Printing
Maintenance
