Cooling system

Cooling System Features

• The coolant pump can be serviced without disconnecting

radiator hoses.

• Both the glow plug sleeves and the injector sleeves are

stainless steel.

Cooling System Features

• Coolant Pump

• Stainless Steel Injector Sleeves

• Stainless Steel Glow Plug Sleeves

Internal Coolant Flow
