Item Capacity
Ford Part Name or
Equivalent
Ford Part Number / Ford
Specification
Engine coolant 6.1 quarts (5.7L)
Motorcraft威 Specialty
Orange Engine Coolant
4
VC-3-B (US)
CVC-3-B (Canada) /
WSS-M97B44-D
Power steering fluid
Fill to between
MIN and MAX
lines on reservoir
Motorcraft威 Power
Steering Fluid
XL-14 /
MERCON威 V
Windshield washer
fluid
Fill as required
Motorcraft威 Premium
Windshield Washer
Concentrate (US)
Motorcraft威 Premium
Quality Windshield
Washer Fluid (Canada)
ZC-32-A (US)
CXC-37-(A, B, D, and F)
(Canada) /
WSB-M8B16-A2 /- -
Fuel tank
15.4 gallons
(58.3L)
——
1
Approximate dry fill capacity including transmission fluid cooling system, actual refill capacities
will vary based on vehicle application and transmission fluid cooling system (i.e. coolers size,
cooling lines, auxiliary cooler capacities). The amount of transmission fluid and fluid level should
be set by the indication on the dipstick’s normal operating range.
2
Automatic transmissions that require MERCON威 LV should only use MERCON威 LV fluid. Refer to
scheduled maintenance to determine the correct service interval. Use of any fluid other than the
recommended fluid may cause transmission damage.
3
Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the
requirements of Ford specification WSS-M2C945-A and the API Certification mark.
4
Add the coolant type originally equipped in your vehicle.
Maintenance and Specifications
263
2012 Transit Connect (tst)
Owners Guide, 1st Printing
USA (fus)
PAGE POSITION: 263 JOB: @zeta.tweddle.com/ford_pdm/ford/own2002/835536-en-tst/og pubnum:
