153
[SV42172( M)03/94]
eighteen pica chart:0020966-B
%
*
[SV42200( ALL)06/95]
Checking and Replacing Fuses
*
[SV42300( ALL)02/95]
If you need to check a fuse, follow these steps:
[SV42600( M)10/92]
1. Remove the fuse panel cover by squeezing
together the cover release tabs as you apply
a slight pulling motion at the same time. The
underside of the cover contains five spare
fuses and a fuse pulling tool in case you
need to replace a blown fuse.
*
[SV43200( M)03/94]
The spare fuses for your vehicle are color coded
as follows: 10 amp — red, 15 amp — light blue,
20 amp — natural, 30 amp — light green.
*
[SV43300( ALL)06/95]
2. On the fuse panel cover, find the number of
the fuse you want to check. The diagram on
the cover tells you where to locate the fuse
on the panel.
*
[SV43350(B FM)10/92] The underside of the cover also contains a
fuse pulling tool in case you need to replace
a blown fuse.
