85
[RE15520( M)05/95]
RWARNING
Use of an improper jack could result in
personal injury if jack slippage occurs.
[RE19230( M)06/90]
2. To raise front wheels, position jack under
bracket in front of axle, as shown.
[RE19260( M)06/90]
3. To raise rear wheels, position jack under
axle, against edge of spring bracket.
*
[RE21100( FM)03/91]
one third page art:0020725-A
Positioning the jack
[RE21215( M)06/90]
NOTE: Remove wheelcover/hubcaps from
wheels as necessary to access the lug
nuts.
[RE21230( M)06/90]
❑
Use a jack to raise the vehicle slightly. Loosen
the wheel lug nuts, but do not remove them
until the tire is raised off the ground.
[RE21245( M)06/90]
❑
Raise the vehicle until the wheel is clear of
the ground. Finish removing the wheel lug
nuts and wheel.
[RE21255( M)05/95]
F-Super Duty Motorhome Chassis uses
two-element swiveling lug nuts (and wheels
designed to accommodate such lug nuts).
File:ltrem.ex
Update:Tue Jun 20 16:45:33 1995
