Ford Econoline E-150 - Page 194

Fuse or relay
location
Fuse amp
rating
Protected components
53 10A* Anti-lock brake system run/start
feed
54 10A* Fuel pump relay coil
55 — Not used
56 — Not used
57 20A* Trailer tow park lamp
58 15A* Trailer tow backup lamp
59 — Not used
60 — One-touch integrated start
(diode)
61 — Not used
62 HC micro relay Auxiliary switch #2
63 30A** Trailer tow battery charge
64 — Not used
65 20A** Power point 2 (glove box)
66 20A** Power point 3 (left B-pillar)
67 20A** Power point 1 (instrument panel)
68 50A** Modified vehicle
69 — Not used
70 30A** Stripped chassis
71 — Not used
72 20A** Cigar lighter / Power point
73 — Not used
74 30A** Power seat
75 20A* Vehicle power 1, Powertrain
control module power
76 20A* Vehicle power 2, Powertrain
control module – emission related
powertrain components
77 10A* Vehicle power 3, Powertrain
control module – general
powertrain components
Fuses 193
2013 Econoline (eco)
Owners Guide gf, 3rd Printing, May 2013
USA (fus)
