Fuse or relay
location
Fuse amp
rating
Protected components
40 20A Not used (spare)
41 15A Radio, Switch illumination,
Automatic dimming rear view
mirror, Inverter
42 10A Auxiliary switch
43 10A Stripped chassis instrument panel
connector #1
44 10A Trailer tow battery charge relay
45 5A Wipers, Stripped chassis Engine
connector 3
46 7.5A Passenger airbag deactivation
indicator
47 30A circuit
breaker
Windows accessory delay
48 Relay Delayed accessory
Fuses 163
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
