Aerodynamic
Sealed Beam
3. Rotate the bulb socket counterclockwise and remove.
4. Carefully pull the bulb straight out of the socket.
To complete installation, follow the removal procedures in reverse order.
Replacing Brake/Tail/Turn/Reverse Lamp Bulbs (Cut-Away Only)
(If Equipped)
1. Make sure the headlamps are off.
2. Remove the four screws and the
lamp lens from lamp assembly.
3. Carefully pull the bulb straight
out of the socket and push in the
new bulb.
192 Maintenance
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
