Protected componentsFuse amp ratingFuse or relay number
Anti-lock brake system and electronic
stability program pump
40A**F7
Electronic stability program valve30A**F8
Not used-F9
Heater blower motor40A**F10
Not used-F11
Powertrain control module relay fuse30A**F12
Starter relay30A**F13
Rear power window (without door control
unit)
25A**F14
Front cigar lighter or power outlet20A**F15
Front power window (without door control
unit)
25A**F16
Rear power outlet20A**F17
Center power outlet20A**F18
Anti-lock brake system and electronic
stability program 15 feed
5A*F19
Horn15A*F20
Stop light switch5A*F21
Battery monitor system15A*F22
Relay coils5A*F23
Light switch module5A*F24
Power exterior mirror (without door control
unit)
10A*F25
Keep-alive power5A*F26
Air conditioner clutch15A*F27
Vehicle power - fuel injector10A*F28
Rear window defroster25A*F29
213
Fuses
