Number Fuse Amperage
Rating
Circuits Protected
1 7.5 amp Power mirror, power
antenna
2 7.5 amp High-mount brakelamp
3 15 amp Parking lamp,
instrument cluster
gauges
4 10 amp Left headlamp, lamp
out warning
5 10 amp OBD system
6 7.5 amp Air bag system, blower
relay, EATC
7 7.5 amp Illumination switches
8 10 amp Right headlamp, fog
lamp system, DRL,
lamp out warning
9 10 amp EATC system, seat
memory, message
center, cellular phone,
autolamps
10 7.5 amp EATC system, rear
blower, speed control,
GEM system, brake
interlock, overhead
console, automatic
ride control, lamp out
warning
11 7.5 amp Warning lamps,
autolamp
12 10 amp Front washer, rear
washer & wiper
