Replacing the headlamps
1. With the flat side of the bulb’s
base facing upward, insert the
glass end of the bulb into the
socket. Turn the bulb left or right
to line up the grooves in the
plastic base with the tabs in the
socket. Push the bulb into the
socket until the plastic base
contacts the rear of the socket.
2. Slip the retaining ring over the
plastic base until it hits the rear of
the socket. Lock the ring by
rotating it clockwise until you feel
it stop.
3. Press the electrical connector
into the rear of the plastic base
until it snaps, locking it into
position.
4. Turn the headlamps on and
ensure they work properly.
Foglamps (if equipped)
1. Disconnect the electrical
connector from the back of the
foglamp by turning it
counterclockwise.
2. Remove the bulb by lifting the
retaining clip and pulling the bulb
from the assembly.
3. Replace the bulb and insert the
bulb assembly back into the
foglamp.
LIFT
uno_foglamps
Maintenance and care
211
