Compass zone adjustment
1. Determine which magnetic zone
you are in by referring to the zone
map.
2. Press and hold the MODE
control until VAR appears in the
display, then release. The display
should show the current zone
number.
3. Press the MODE control until
the desired zone number appears.
The display will flash and then
return to normal operation. The
zone is now updated.
Compass calibration adjustment
Perform this adjustment in an
open area free from steel
structures and high voltage lines:
• Press and hold the MODE
control until CAL appears in the
display (approximately eight
seconds) and release.
• Drive the vehicle slowly (less
than 5 km/h [3 mph]) in circles
1
2
3
4
5
6
78
9
10
11
12
13
14
15
LAMP
MODE
LAMP
9 VAR
LAMP
MODE
LAMP
CAL
uno_adjust-calibration
Controls and features
51
