Liftgate ajar (RTT): Displays
when the ignition is in the on
position and the trunk is open.
Low washer fluid (RTT):
Illuminates when the windshield
washer fluid is low.
Turn signal: Illuminates when the
left or right turn signal or the
hazard lights are turned on. If the
indicators flash faster, check for a burned out bulb.
High beams: Illuminates when the
high beam headlamps are turned on.
Fog lamps: Illuminates when the
fog lamps are turned on.
Grade assist (RTT) (if
equipped): Illuminates when grade
assist is turned on.
Transmission Tow/Haul Feature
(RTT) (if equipped): Displays
when the Tow/Haul feature has been
activated. Refer to the Driving
chapter for transmission function and operation. If the light flashes
steadily, have the system serviced immediately, damage to the
transmission could occur.
Instrument Cluster
17
2012 Explorer (exp)
Owners Guide, 1st Printing
USA (fus)
