Removing the spare tire and jack
If the 3rd row seat is stowed in the floor, you will need to unstow it
(raised position) to access the spare tire and jack. Refer to Unstowing
the third row seat in the Seating and Safety Restraints chapter for this
procedure.
1. Remove the floor filler and
carpeted floor panel located in the
rear of the vehicle.
2. Remove the wing nut that secures
the spare tire by turning it
counterclockwise.
3. Lift and remove the spare tire
from the spare tire well.
Roadside Emergencies
337
2012 Explorer (exp)
Owners Guide, 1st Printing
USA (fus)
