Protected ComponentsFuse RatingFuse or Relay
Number
Daytime running lamps on/off relay coil.
Headlamp daytime running lamp relay
feed.
Instrument panel fuses #25, 31.
Vehicle power.
30A
2
J3
Powertrain control module relay feed.
Power distribution box fuse F16, F17, F18,
J22.
Cigar lighter feed.
20A
2
J4
Diagnostic tool connector.
Not used.—J5
Starter relay feed.
30A
2
J6
Starter motor solenoid.
Anti-lock brake system module (Hydro-
boost).
40A
2
J7
Power brake assist motor (HydroMax).
60A
2
Power distribution box fuse #F20.
Trailer tow park lamps.
20A
2
J8
Instrument panel fuse #4, 10, 16, 22.
50A
2
J9
HydroMax anti-lock brake system module.
60A
2
J10
Hydroboost anti-lock brake system
module.
40A
2
Fuel pump relay feed.
20A
2
J11
Fuel injectors.
Mass air flow sensor.
Fuel pump motor.
Powertrain control module.
Trailer tow electronic brake.
30A
2
J12
Ignition switch feed (instrument panel
fuses #1, 5, 7, 11, 13, 14, 17, 19, 23, 36).
40A
2
J13
(Power distribution box fuse #F19, F22,
F21).
Not used.—J14
