Protected ComponentsFuse RatingFuse or Relay
Number
Not used.—30
Body builder left-hand low beam head-
lamp feed.
10A31
Not used.—32
Body builder reverse lamp power.10A33
Body builder reverse gear.10A34
Trailer tow reverse lamps.
Body builder high beam feed.20A35
High beam indicator.
Transmission control switch.10A36
Not used.—37
Body builder off/run.10A38
Not used.—39
Not used.—40
Instrument cluster lighting/switch illumin-
ation.
10A41
Not used.—42
Not used.—43
Not used.—44
Trailer tow right-hand direction indicator.—Relay 1
Trailer tow left-hand direction indicator.—Relay 2
Right-hand direction indicator.—Relay 3
Left-hand direction indicator.—Relay 4
Not used.—Relay 5
Daytime running lamps.—Relay 6
Parking brake.
Daytime running lamps on/off.—Relay 7
Not used.—Diode 1
83
Motorhome (TY3) Canada/United States of America, enUSA, Edition date: 201712, Second Printing
Fuses
