Fuse/Relay
Location
Fuse Amp
Rating
Protected circuits
60 10A Interior light, Driver door switch
pack, Glove box illumination,
Overhead console switch bank
61 20A Cigar lighter, Power point
62 5A Rain sensor module, Humidity
sensor, Electrochromatic rear
view mirror
63 — Not used
64 — Not used
65 10A Trunk/liftgate release
66 20A DD FF unlock supply, double lock
67 7.5A SYNC威, Multifunction Display,
Global positioning system (GPS)
module, Compass
68 — Not used
69 5A Instrument cluster
70 20A Central lock and unlock supply
71 10A Heating control head (manual
A/C), Duel electronic automatic
temperature control
72 7.5A Steering wheel module
73 5A Data link connector
74 15A Low beam headlamp supply
75 15A Fog lamp supply
76 10A Reversing lamp supply
77 20A Windshield washer supply
78 5A Ignition switch, Start button
79 15A Radio, Navigation DVD player,
Touch screen, Hazard light switch,
Door lock switch
80 20A Sunroof supply
81 5A R F receiver
Roadside Emergencies
305
2012 Focus (foc)
Owners Guide, 5th Printing
USA (fus)
