Ford Freestyle - Page 225

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
28 80A* SJB power, SJB (Circuit breaker,
Fuses 6, 7, 9, 10, 11 and 15)
29 30A* Driver window motor
30 — Not used
31 30A* Auxiliary A/C rear blower motor,
Auxiliary coolant pump
32 30A* Driver seat motors, Memory
module
33 30A* Ignition switch (to SJB)
34 — Not used
35 40A* Front A/C blower motor
36 10A** Auxiliary coolant pump
37 — Not used
38 — Not used
39 1A Diode PCM
40 1A Diode A/C clutch
41
1
⁄ 2 ISO relay Fog lamps
42 — Not used
43
1
⁄ 2 ISO relay A/C clutch
44
1
⁄ 2 ISO relay Fuel pump driver module, Fuel
pump
45 30A** Front wiper, Front washer
46 5A** Heated Positive Crankcase
Ventilation (PCV) valve
47 25A** Rear wiper, Rear washer
48 10A** TCM, EVMV, Canister vent, ESM,
Exhaust Gas Oxygen heaters, A/C
clutch
49 15A** PCM, Injectors, Ignition coils,
Mass Air Flow (MAF) sensor
50 Full ISO relay PCM relay, PDB fuses 40 and 41
51 Full ISO relay Starter motor solenoid
2007 Freestyle (219)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
225
