THE
TRUE
DEFINITION
OF QUALITY
INSTRUMENT
PANEL
Welcometo the truedefinition of quality – bold stylingand
great
driving dynamics combined. Ford Fusion’s s leek and
athletic
lines assure heads will turn; just as the dynamic
powertrain assures a powerful yet effortless drive. From the
sensuous, modern interior, to the available V6 engine that lies
beneath the hood, every component has been designed with
you in mind. Sporty, comfortable and efficient, the Ford Fusion
has it all. This Quick Reference Guide will help you quickly get
to know the features of your new Ford Fusion. For more
detailed information and important safety information, refer to
your Owner’s Guide.
Use extreme caution when using any device or feature that may
take your attention off the road. Your primary responsibility is
the safe operation of the vehicle. Only use non-essential
features and devices when it is safe to do so.
1. POWER OUTSIDE MIRRORS
Rotate the control clockwise to adjust the right mirror. Rotate the control counterclockwise to
adjust the left mirror. Move the control in the direction you wish to tilt the mirror. Return the
control to the center position to lock the mirrors in place.
2. HEADLAMPS, FOG LAMPS (if equipped)
& PANEL DIMMER CONTROL
Turn the control one position to the right to turn on the parking lamps,
instrument panel lamps, license plate lamps and tail lamps. Turn the control
to the second position on the right to turn on the headlamps. Turn the control
one position to the left to activate the autolamp feature (if equipped), which
automatically turns the exterior lamps on and off, based on available daylight. Pull the control
towards you to activate the fog lamps
. (The fog lamps will not operate
when the control is turned
off ( ) or when the high beams are on.) Use the panel dimmer control to
adjust the level of brightness
on the instrument panel during parking lamp and headlamp operation.
Move the control to the full
upright position, past the detent, to turn on the interior lamps.
3. STEERING WHEEL CONTROLS (if equipped)
The appearance and functionality of your vehicle’s steering wheel controls may
vary according to your option package. Refer to your Owner’s Guide for a
complete description of all possible options. To set the speed control, press
and release ON. Accelerate to the desired speed. Press and release the SET (+)
control. Take your foot off the accelerator pedal. The speed control indicator
light will illuminate in the cluster. To set a higher speed: press and hold SET
(+) until the desired speed is reached, or briefly press SET (+) to increase the
speed by small amounts. To set a lower speed: press and hold SET (-) until the
desired speed is reached, or briefly press SET (-) to decrease the speed by
small amounts. Press RESUME to return to the previously set speed. To turn
speed control off, depress the brake pedal or press OFF.
Press – VOL + to decrease/increase the volume. Press to access the
previous/next preset radio station, CD track or preset satellite radio channel (if
equipped). Press to activate the Voice recognition system. Refer to your SYNC or Navigation
supplement(if equipped) for more information. Press MEDIA repeatedly to scroll through all possible
media sources (AM, FM1, FM2, CD . . .etc ).
Press to answer a call if equippedwith SYNC. Press and hold to end a call. Refer to your
SYNC supplement for more information.
4. TILT/TELESCOPIC STEERING WHEEL LEVER
Push the lever down to unlock the steering column. Move the steering wheel
up or down and in or out to find the desired position. While holding the
steering wheel in place, pull the lever up to lock the steering column.
5. MESSAGE CENTER (if equipped)
The message center displays important vehicle information through a constant
monitoring of vehicle systems. The system will also notify you of potential vehicle
problems with a display of system warnings followed by a long indicator chime. To
access the selectable features press the following buttons on the instrument panel:
INFO: Press to scroll through the following displays:Odometer, Trip Odometer A or B,
Distance toEmpty, Average Fuel Economy, Average Speed, Trip elapsed time 1 or 2 and
compass (if equipped).
RESET: Press and hold to select and reset functions shown in the Info (Information) and Setup Menu.
SETUP: Press to scroll through: System Check, Units (English/Metric), Language (language choices),
Easy entry/exit seat (if equipped) and Reverse Sensing System (if equipped). For more
information, please refer to your Owner’s Guide.
6. AMBIENT LIGHTING (if equipped)
Your vehicle may be equipped with an ambient lightingfeature which illuminatesthe footwells, cupholders
and the center console bin with your choice of seven colors. Press the control repeatedly to turn the
feature on, cycle through your color options, and turn the feature off.
7. CENTER CONSOLE
Your center console has a variety of features. In addition to cupholders and storage, there is also a 12V
auxiliary power point for powering electrical devices that require up to 12V and an auxiliary input jack
which allows you to play audio from a portable music player through the vehicle speakers. If your
vehicle is equipped with SYNC, you will also have a USB port which allows you to plug in media
playing devices, memory sticks and also charge devices (if supported). For more information on
these features, please refer to your Owner’s Guide.
8.
ADVANCETRAC>
(if equipped)
The AdvanceTrac stability enhancement system helps avoid wheel spin and loss of traction (Traction
control™) as wellas helping you to avoid skids or lateral slides (Electronic Stability Control). These
features help you to maintain stability and steerability of your vehicle during a variety of road
conditions. If your vehicle becomes stuck in the snow, mud or sand, try turning off the AdvanceTrac
system to allow wheel spin and help increase momentum to help dig the vehicle out. The system
defaults to on and the control will illuminate when turned off. Refer to your Owner’s Guide for safety
information and more details.
9.
PASSENGER AIRBAG OFF
Your vehicle has a safety feature that automatically knows when to turn off the passenger airbag
based on the occupant’s size and weight. When the system senses no weight or light to medium
weight (such as a heavy binder or suitcase), in the front passenger seat, the PASS AIRBAG OFF
indicator lamp will illuminate, signifying the passenger airbag is turned off. Refer to your Owner’s
Guide for safety information and more details.
10.
GLOVE BOX CD STORAGE
Your vehicle is equipped with a special area for your CD storage. It is located inside the glove box,
to the right of the main bin.
1. Service Engine Soon Light
The Service Engine Soon
light illuminates briefly when
the ignition is turned on. If it
remains on or is blinking
after the engine is started,
the On Board Diagnostics
System (OBD-II) has detected
a malfunction. Drive in
a moderate fashion and
have your vehicle serviced
immediately by an
authorized dealer.
2. Anti-lock Brake System
(ABS) Warning Light
The ABS light illuminates
briefly when the ignition is
turned on. If the ABS light
remains on or flashes after
the engine is started, have
the system serviced
immediately by your
authorized dealer. Normal
braking (without ABS) will
still be functional unless the
brake system warning light
is also illuminated. Note: It
is normal to feel a pedal
pulsation or hear a slight
noise when the ABS system
is activated.
3. Airbag Readiness Light
The airbag readiness light
illuminates briefly when the
ignition is turned on. If this
light remains on or continues
to flash after the engine is
started, the supplemental
restraint system has
detected a malfunction.
If a malfunction is detected,
a chime will also sound.
Have the system serviced
immediately by an
authorized dealer.
4. Brake System Warning
Light The brake system
warning light illuminates
briefly when the ignition is
turned on. This light will
remain on when the parking
brake is applied and the
ignition is on. If this light
remains on after releasing
the parking brake, this
indicates a low brake fluid
level or a brake system
malfunction. Have the brake
system inspected immediately
by an authorized dealer.
5. Check Fuel Cap Light
This light illuminates when
the fuel cap may not be
properly installed. If you
continue to drive with this
light illuminated, the
Service Engine Soon light
may come on.
6.
Throttle Control /
Transmission
Light
This light
illuminates when a powertrain
or AWD (if equipped)
malfunction has been
detected. Contact an
authorized dealer as soon
as possible.
7.
Traction Control
™
Light
This light illuminates when
Traction Control
™
is active.
If the light remains on,
have the system serviced
immediately by an
authorized dealer.
2
1
3
4 3 1095
7
1
2
3
4
5
6
86 7
