HIGH-VOLTAGE SERVICE DISCONNECT
To gain access to the high-voltage service disconnect, the rear seat must
be lowered. The rear seat is released from the trunk area.
• Locate the seat backrest latch release levers (2) between the high-voltage
battery and the body sheet metal.
• Push the release lever toward the outboard side of the vehicle.
FCS-14265-10
9
2010 Fusion Hybrid, Milan Hybrid Emergency Response Guide, 02/2009
