You can switch dome lamps on by pressing

the button.

AMBIENT LIGHTING (IF EQUIPPED)

The ambient lighting system is adjusted

with the MyFord Touch. See MyFord

Touch™ (page 352).

74

Fusion/Mondeo (CC7)

Lighting
