Ford Ranger 2008 - Air-Conditioning System; Vent Operation

Black plate (125,1)
Vent Operation
qAdjusting the Vents
Directing airflow
Side Vents
To adjust the direction of airflow, open the
vents and rotate them left and right.
Push
Centre Vents
To adjust the direction of airflow, move
the adjustment knob.
Knob
Open
Interior Comfort
Air-Conditioning System
6-3
