Seating and Safety Restraints
105
*
[SS00549(R)01/96]
Center Facing Jump Seat — SuperCab Only
[SS00551(R)01/96]
To open the seat, pull inboard and down on the seat handle. To
stow the seat, pull seat bottom back to the fully upright
position. The jump seats should be kept in the stored position
for easier access to the rear cab area.
[SS00560(R)01/96]
10-1/2 pica
art:0020232-B
Center facing jump seat in stowed position
*
[SS00570(R)01/96]
R WARNING
Do not install a child seat in a center facing jump seat.
[SS00580(R)01/96]
Tilt Slide Seat (If equipped)
[SS00590(R)01/96]
SuperCab only
[SS00610(R)01/96]
With the front seatback tilted forward, the tilt slide seat can be
moved to provide additional entry space to access the rear seat
compartment of the vehicle.
*
[SS00620(R)01/96]
To operate the tilt slide seat:
[SS00622(R)01/96] 1. Lift the seatback release lever on the outboard side of the
seat cushion to unlock the slide mechanism and seatback.
*
[SS00624(R)01/96] 2. Push the seat assembly forward to provide entry space to the
rear seat compartment of the vehicle.
