Instrumentation
11
*
[IS03800(R)01/96]
Anti-lock Brake Warning Light
[IS03925(R)01/96]
To check the ABS brake warning light, turn the ignition key to
ON. The ABS brake warning light should glow momentarily.
[IS03985(R)01/96]
NOTE: If the ABS brake warning light does not glow
momentarily, have your vehicle’s electrical system
checked immediately. If the light begins to flash in a
repeatable flash sequence, check the anti-lock system
continuous power fuse and brakelamps for proper
operation.
[IS04050(R)01/96]
6 pica art:0021146-A
Anti-lock warning light symbol
*
[IS04100(R)03/96]
R WARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
*
[IS04110(R)03/96]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
%
*
[IS04150(R)03/96]
Safety Belt Warning Light and Chime
[IS04301(R)04/96]
The safety belt warning light/chime reminds you to fasten your
safety belt. One of the following will take place:
[IS04325(R)05/96]
■ If the safety belt is not buckled before the key is turned to
the ON position, the light comes on for one to two minutes
and the chime sounds for 4 to 8 seconds.
